1/2 „wing nut eg for AFG pressure reducers with seal

Beer or CO₂ wing nut 1/2″

Robust connection solution made of nickel-plated brass for beverage lines with 1/2-inch thread connection

The 1/2″ wing nut is a proven connection component in dispensing and beverage technology. It is used for the secure and leak-proof installation of hose nozzles with flat sealing surfaces on pressure reducers, distributors or other components with a 1/2″ external thread. Thanks to its flat sealing design and the hard seal included in the scope of delivery, it is particularly suitable for use in CO₂ and AFG lines – especially when connected to pressure reducers with a 1/2″ outlet.

Technical data:

• Product: Wing nut for beverage lines

• Thread connection: 1/2″ female thread (BSP – cylindrical)

• Material: Brass, nickel-plated
  – robust, durable, corrosion-resistant

• Sealing principle: Flat sealing

• Includes: Hard seal for secure sealing with CO₂ and AFG

• Suitable for nozzles with a base:
  – 4 mm straight
  – 7 mm straight

Special features and advantages:

• Versatile:
  Ideal for connecting beverage lines (beer, CO₂, AFG) to pressure reducers or devices with 1/2″ external thread

• Easy to use thanks to wing handles:
  Tools are not usually required – the wing nut can be tightened securely by hand

• Reliable sealing:
  In combination with the supplied hard seal, a flat-sealing connection is created that remains absolutely tight even in CO₂ systems

• Compact design:
  Easy to install even in confined spaces

Typical areas of application:

• Connection of beer hoses to CO₂ pressure regulators with 1/2″ outlet

• Connection of CO₂ supply lines in dispensing systems

• Use in AFG lines, e.g. for soft drinks or water

• Catering establishments, mobile bars, home dispensing systems, beverage technology

Processing instructions:

1. Prepare the seal:
   Place the enclosed hard seal on the flat sealing end of the hose nozzle used.

2. Insert the nozzle:
   Insert the hose nozzle together with the seal through the opening of the wing nut.

3. Assembly:
   Screw the wing nut onto the 1/2″ thread of the pressure reducer or connection piece by hand and tighten it hand-tight.
   Readjustment with a tool is only necessary if required.
